How to set up MySQL Cluster on Ubuntu

We’ll show you, how to set up MySQL Cluster on Ubuntu. The MySQL NDB Cluster integrates the standard MySQL server with an in-memory clustered storage engine called NDB (Network DataBase). We will use a total of 4 virtual servers, one for the management, one SQL node and two data nodes:

• 172.16.1.1 – management VPS
• 172.16.1.2 – SQL VPS
• 172.16.1.3 – data1 VPS
• 172.16.1.4 – data2 VPS

1. Install and Configure MySQL Cluster on the Management VPS

Download the latest version of MySQL Cluster to a directory of your virtual server and extract it using the following commands:

cd /opt/
wget http://dev.mysql.com/get/Downloads/MySQL-Cluster-7.5/mysql-cluster-gpl-7.5.4-linux-glibc2.5-x86_64.tar.gz -O mysql-cluster.tar.gz
tar -xvzf mysql-cluster.tar.gz -C /opt/
mv mysql-cluster-* mysql

Run the following commands:

cd /opt/mysql/
cp bin/ndb_mgm* /usr/local/bin/
chmod 755 /usr/local/bin/ndb_mgm*

Create a directory named ‘mysql-cluster’

mkdir -p /var/lib/mysql-cluster/

Then, create a new configuration named ‘config.ini’:

vi /var/lib/mysql-cluster/config.ini

add the following lines to it:

[ndbd default]
NoOfReplicas=2
# Memory to allocate for data storage
DataMemory=2G
# Memory to allocate for index storage
IndexMemory=512M

[mysqld default]

[ndb_mgmd default]

[tcp default]

# Management VPS
[ndb_mgmd]
# Enter the hostname or IP address of the Management VPS
hostname=172.16.1.1

# SQL VPS
[mysqld]
# Enter the hostname or IP address of the SQL VPS
hostname=172.16.1.2

# Data1 VPS
[ndbd]
# Enter the hostname or IP address of the Data1 VPS
hostname=172.16.1.3
DataDir= /var/lib/mysql-cluster

# Data2 VPS
[ndbd]
# Enter the hostname or IP address of the Data2 VPS
hostname=172.16.1.4
DataDir=/var/lib/mysql-cluster

Do not forget to change the hostnames/IP addresses according to your actual server hostnames/IP addresses.

2. Install and Configure MySQL Cluster on the SQL VPS

Check if there are MySQL packages already installed:

dpkg -l | grep mysql

rc  libmysqlclient18:amd64               5.5.49-0ubuntu0.14.04.1                  amd64        MySQL database client library
ii  mysql-client                         5.7.16-0ubuntu0.16.04.1                  all          MySQL database client (metapackage depending on the latest version)
ii  mysql-client-5.7                     5.7.16-0ubuntu0.16.04.1                  amd64        MySQL database client binaries
ii  mysql-client-core-5.7                5.7.16-0ubuntu0.16.04.1                  amd64        MySQL database core client binaries
ii  mysql-common                         5.7.16-0ubuntu0.16.04.1                  all          MySQL database common files, e.g. /etc/mysql/my.cnf
ii  mysql-server                         5.7.16-0ubuntu0.16.04.1                  all          MySQL database server (metapackage depending on the latest version)
rc  mysql-server-5.5                     5.5.49-0ubuntu0.14.04.1                  amd64        MySQL database server binaries and system database setup
ii  mysql-server-5.7                     5.7.13-0ubuntu0.16.04.2                  amd64        MySQL database server binaries and system database setup
ii  mysql-server-core-5.7                5.7.13-0ubuntu0.16.04.2                  amd64        MySQL database server binaries

Remove these packages and their configurations using:

apt-get purge mysql-c* mysql-s*

Or, remove packages and configuration files listed by the ‘dpkg -l | grep mysql’ command above using:

apt-get purge mysql-client mysql-client-5.7 mysql-client-core-5.7 mysql-common mysql-server mysql-server-5.5 mysql-server-5.7 mysql-server-core-5.7 libmysqlclient18

Download the latest version of MySQL Cluster available at ‘http://dev.mysql.com/downloads/cluster/’ to the opt directory of your virtual server and extract it using the following commands:

cd /opt/
wget http://dev.mysql.com/get/Downloads/MySQL-Cluster-7.5/mysql-cluster-gpl-7.5.4-linux-glibc2.5-x86_64.tar.gz -O mysql-cluster.tar.gz
tar -xvzf mysql-cluster.tar.gz -C /opt/
Run the following commands:

mv mysql-cluster-* mysql
mv mysql /usr/local/
cd /usr/local/mysql/
mv bin/* /usr/local/bin/
rm -rf bin/
ln -s /usr/local/bin /usr/local/mysql/
cp support-files/mysql.server /etc/init.d/mysql
systemctl enable mysql
mysqld --initialize
chown -R root:mysql /usr/local/mysql/
chown -R mysql /usr/local/mysql/data/

Edit the MySQL configuration file (/etc/my.cnf):

vi /etc/my.cnf

add the following lines:

[mysqld]
datadir=/usr/local/mysql/data
socket=/tmp/mysql.sock
user=mysql

ndbcluster
ndb-connectstring=172.16.1.1

[mysql_cluster]

ndb-connectstring=172.16.1.1

[mysqld_safe]
log-error=/var/log/mysqld.log
pid-file=/var/run/mysqld/mysqld.pid

Log in to the management VPS via SSH and run the following command:

ndb_mgmd -f /var/lib/mysql-cluster/config.ini --configdir=/var/lib/mysql-cluster/

In order to configure ndb_mgmd to start on boot, add the following command to ‘/etc/rc.local’:

vi /etc/rc.local

and add:

ndb_mgmd -f /var/lib/mysql-cluster/config.ini --configdir=/var/lib/mysql-cluster/

before the ‘exit 0’ line and save the file.
Start the MySQL service on the SQL VPS:

service mysql start

In order to improve the security of your MySQL installation, run:

/usr/local/mysql/bin/mysql_secure_installation

3. Install and Configure MySQL Cluster on the Data VPSes

Check if there are MySQL packages already installed using:

dpkg -l | grep mysql

Remove them, including the configuration files:

apt-get purge mysql-client mysql-client-5.7 mysql-client-core-5.7 mysql-common mysql-server mysql-server-5.5 mysql-server-5.7 mysql-server-core-5.7 libmysqlclient18

Download and extract the latest version of MySQL Cluster to the opt directory on the data1 VPS:

cd /opt/
wget http://dev.mysql.com/get/Downloads/MySQL-Cluster-7.5/mysql-cluster-gpl-7.5.4-linux-glibc2.5-x86_64.tar.gz -O mysql-cluster.tar.gz
tar -xvzf mysql-cluster.tar.gz -C /opt/

Run the following commands:

mv mysql-cluster-* mysql
mv mysql /usr/local/
chown -R root:mysql /usr/local/mysql/
cd /usr/local/mysql/
mv bin/* /usr/local/bin/
rm -rf bin/
ln -s /usr/local/bin /usr/local/mysql/

Edit the MySQL configuration file:

vi /etc/my.cnf

add the following lines:

[mysqld]
datadir=/usr/local/mysql/data
socket=/tmp/mysql.sock
user=mysql

ndbcluster
ndb-connectstring=172.16.1.1

[mysql_cluster]

ndb-connectstring=172.16.1.1

[mysqld_safe]
log-error=/var/log/mysqld.log
pid-file=/var/run/mysqld/mysqld.pid

Run the following commands:

mkdir /var/lib/mysql-cluster
chown -R mysql /var/lib/mysql-cluster
cd /var/lib/mysql-cluster
ndbd --initial
echo "ndbd" > /etc/init.d/ndbd
chmod 755 /etc/init.d/ndbd

Repeat the same procedure on the Data2 VPS.

In order to check the MySQL cluster status, run the following command on the management VPS:

ndb_mgm -e show

The output should look like this:

Connected to Management Server at: localhost:1186
Cluster Configuration
---------------------
[ndbd(NDB)]     2 node(s)
id=3    @172.16.1.3  (mysql-5.7.16 ndb-7.5.4, Nodegroup: 0, *)
id=4    @172.16.1.4  (mysql-5.7.16 ndb-7.5.4, Nodegroup: 0)

[ndb_mgmd(MGM)] 1 node(s)
id=1    @172.16.1.1  (mysql-5.7.16 ndb-7.5.4)

[mysqld(API)]   1 node(s)
id=2    @172.16.1.2  (mysql-5.7.16 ndb-7.5.4)

That is it. The setup of the MySQL cluster is now complete.

---
